Base64는 byte 배열을 읽는 방식을 의미합니다. (보통 우리가 사용하는 UTF8, ASCII 등이 있지요)

Base64는 3byte (24bit) 단위로 자르고, 6bit씩을 취해 해당 값에 매칭되는 base64테이블로 매핑해줍니다.

이 때, 원문이 없는 경우는 "=" 문자열을 넣어 길이를 채워줍니다.

아래는 aB1@ 를 base64로 변환 한 결과입니다.



Base64 Table : ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/



base64 나눠지는 형식





일단 C# 에서 제공되는 코드가 있는데 내부 구현이 궁금하여 테스트 해보게 되었습니다.



[C# base64 기존 제공]

string text = "aB1@"; //원본
byte[] bytes = Encoding.UTF8.GetBytes(plainText); //원하는 인코딩으로 byte 만들기
string base64String = Convert.ToBase64String(bytes); //byte배열 -> base64 텍스트 변환
byte[] base64bytes = Convert.FromBase64String(base64String); //base64 텍스트 -> byte배열 변환
string originText = Encoding.UTF8.GetString(base64bytes); //원본과 일치





[C# 직접 구현 - 4Byte int 형으로 비트 값 연산에 사용 (GPT 도움..!)]

using System;
using System.Collections.Generic;
using System.Text;

class Test
{
    private const string table = "ABCDEFGHIJKLMNOPQRSTUVWXYZabcdefghijklmnopqrstuvwxyz0123456789+/";
    private const string plainText = "aB1@";

    static void Main()
    {
        byte[] bytes = Encoding.UTF8.GetBytes(plainText);

        string base64Text = Base64Encoding(bytes); //직접 구현
        string base64Text2 = Convert.ToBase64String(bytes); //기존 제공

        Console.WriteLine("base64 텍스트 : " + base64Text);
        Console.WriteLine("base64 텍스트2 : " + base64Text2);

        byte[] base64bytes = Base64Decoding(base64Text); //직접 구현
        byte[] base64bytes2 = Convert.FromBase64String(base64Text2); //기존 제공

        Console.WriteLine("원본 복원 : " + Encoding.UTF8.GetString(base64bytes));
        Console.WriteLine("원본 복원2 : " + Encoding.UTF8.GetString(base64bytes2));
    }

    private static string Base64Encoding(byte[] bytes)
    {
        StringBuilder sb = new StringBuilder();

        for (int i = 0; i < bytes.Length; i += 3)
        {
            int value = 0;
            int paddingCount = 0;

            //3byte씩 합쳐주기
            for (int j = i; j < i + 3; ++j)
            {
                value = value << 8;

                if (j < bytes.Length)
                {
                    value |= bytes[j];
                }
                else
                {
                    paddingCount++;
                }
            }

            //Masking
            //1111 1100 0000 0000 0000 0000 (0x3F << 6 << 6 << 6)
            //0000 0011 1111 0000 0000 0000 (0x3F << 6 << 6)
            //0000 0000 0000 1111 1100 0000 (0x3F << 6)
            //0000 0000 0000 0000 0011 1111 (0x3F)
            int masking = 0x3F << 6 << 6 << 6;

            //3byte를 6bit로 쪼개기 (없다면 패딩처리 '=')
            for (int j = 0; j < 4; ++j)
            {
                if (paddingCount > 3 - j)
                {
                    sb.Append("=");
                }
                else
                {
                    int v = (value & masking) >> 6 * (3 - j);
                    sb.Append(table[v]);
                }

                masking = masking >> 6;
            }
        }

        return sb.ToString();
    }

    private static byte[] Base64Decoding(string text)
    {
        List<byte> byteList = new List<byte>();

        for (int i = 0; i < text.Length; i += 4)
        {
            int value = 0;
            int paddingCount = 0;

            for (int j = i; j < i + 4; ++j)
            {
                value = value << 6;

                if (text[j] != '=')
                {
                    value |= table.IndexOf(text[j]);
                }
                else
                {
                    paddingCount++;
                }
            }

            int masking = 0xFF << 8 << 8;

            for (int j = 0; j < 3; ++j)
            {
                if (paddingCount > (2 - j))
                {
                    break;
                }
                else
                {
                    int v = (value & masking) >> 8 * (2 - j);
                    byteList.Add((byte)v);
                }

                masking = masking >> 8;
            }

            //Console.WriteLine("Processing... " + Encoding.UTF8.GetString(byteList.ToArray()));
        }

        return byteList.ToArray();
    }
}





하위 form2, form3 은 항상 form1보다 앞에 위치!

(Winform) 하위 form2, form3이 form1 앞에 위치


(WPF에 Winform 삽입) form1이 MainWindow 앞에 위치



Form 앞쪽에 고정 시키고 싶은 Form이 있는 경우입니다.

Winform에서는 Owner 속성을 지정해주면 해당 Form보다 항상 앞에 위치하게 됩니다.

WPF에서는 창의 Handle 값을 가져와서 Winform에서 Show 할 때 지정해줄 수 있습니다.



[Winform]

using System;
using System.Drawing;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form1 : Form
    {
        private Form2 form2 = new Form2();
        private Form3 form3 = new Form3();
        private int titleSize = 30;

        public Form1()
        {
            InitializeComponent();
        }

        private void Form1_Load(object sender, EventArgs e)
        {
            form2.Owner = this; //Form3은 Form1 앞에 위치
            form3.Owner = this; //Form3은 Form1 앞에 위치

            form2.Size = new Size(this.Width / 2, this.Height - titleSize);
            form3.Size = new Size(this.Width / 2, this.Height - titleSize);

            form2.Show();
            form3.Show();

            form2.Location = new Point(this.Location.X, this.Location.Y + titleSize);
            form3.Location = new Point(this.Location.X + form2.Size.Width, this.Location.Y + titleSize);
        }

        private void Form1_Move(object sender, EventArgs e)
        {
            form2.Location = new Point(this.Location.X, this.Location.Y + titleSize);
            form3.Location = new Point(this.Location.X + form2.Size.Width, this.Location.Y + titleSize);
        }
    }
}



[WPF 에서 Winform]

using System;
using System.Windows;
using System.Windows.Interop;

namespace WpfApp1
{
    /// <summary>
    /// MainWindow.xaml에 대한 상호 작용 논리
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
        }

        private void Window_Loaded(object sender, RoutedEventArgs e)
        {
            Form1 form1 = new Form1();

            WindowInteropHelper helper = new WindowInteropHelper(this);
            IntPtr handle = helper.Handle; //WPF 핸들값 가져오기

            form1.Show(new Win32Window(handle)); //form1이 항상 윗쪽에!
        }
    }

    class Win32Window : System.Windows.Forms.IWin32Window
    {
        private IntPtr handle;
        public IntPtr Handle
        {
            get
            {
                return handle;
            }
        }

        public Win32Window(IntPtr handle)
        {
            this.handle = handle;
        }
    }
}

Windows 환경에서 사용되는 코드입니다.

WIN API 기반으로 이름(2번째 인자)에 해당하는 Named Mutex 를 통해 내부적 처리를 한다고 합니다.



using System;
using System.Threading;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    static class Program
    {
        /// <summary>
        /// 해당 애플리케이션의 주 진입점입니다.
        /// </summary>
        [STAThread]
        static void Main()
        {
            bool isRunning;
            Mutex mutex = new Mutex(true, "UniqueMutexName", out isRunning); //뮤택스 확인

            if (!isRunning) //이미 해당이름으로 Mutex가 걸려있으면 false 없다면 true
            {
                return;
            }
            Application.EnableVisualStyles();
            Application.SetCompatibleTextRenderingDefault(false);
            Application.Run(new Form1());


            mutex.ReleaseMutex();  // 해제
        }
    }
}

C#, Java 간 암복호화를 사용할 일이 있어서 정리해봅니다.

처리 방법은 2가지가 있습니다.

1. TransformFinalBlock : 바이트 전체를 한번에 처리

2. CryptoStream : 스트림 단위로 잘라서 처리 1MB 이상이면 권장된다고 합니다!

using System;
using System.Security.Cryptography;
using System.Text;

namespace ConsoleApp1
{
    class Program
    {
        private static readonly string KEY = "0123456789abcdef0123456789abcdef"; // 32-byte
        private static readonly string IV = "abcdef9876543210"; // 16-byte

        private static Aes aes;

        static void Main(string[] args)
        {
            aes = Aes.Create();
            aes.Key = Encoding.UTF8.GetBytes(KEY); //CBC므로 32바이트
            aes.IV = Encoding.UTF8.GetBytes(IV); //16바이트 (첫 XOR 값)
            aes.Mode = CipherMode.CBC; //16바이트 단위로 XOR 처리
            aes.Padding = PaddingMode.PKCS7; //패딩 끝 부분 바이트 처리 (부족한 길이 반복)

            string originalText = "Hello, AES-256!";
            Console.WriteLine("Original: " + originalText);

            string encryptedText = Encrypt(originalText);
            Console.WriteLine("Encrypted: " + encryptedText);

            string decryptedText = Decrypt(encryptedText);
            Console.WriteLine("Decrypted: " + decryptedText);
        }

        static string Encrypt(string plainText)
        {
            ICryptoTransform encryptor = aes.CreateEncryptor();
            byte[] inputBytes = Encoding.UTF8.GetBytes(plainText);

            //****************************************************************
            //통 Block 방식
            byte[] encryptedBytes = encryptor.TransformFinalBlock(inputBytes, 0, inputBytes.Length);
            return Convert.ToBase64String(encryptedBytes); //통신용이라면 base64가 안전 (아니면 그냥 UTF8로 해도 괜찮습니다!)

            //****************************************************************
            //Stream 방식 (1MB 이상이면 스트림 방식 권장)
            using (MemoryStream ms = new MemoryStream())
            {
                using (CryptoStream cs = new CryptoStream(ms, encryptor, CryptoStreamMode.Write))
                {
                    cs.Write(inputBytes, 0, inputBytes.Length);
                    cs.FlushFinalBlock();
                }
                return Convert.ToBase64String(ms.ToArray());
            }
        }

        static string Decrypt(string encryptedText)
        {
            ICryptoTransform decryptor = aes.CreateDecryptor(aes.Key, aes.IV);
            byte[] encryptedBytes = Convert.FromBase64String(encryptedText); //Encrypt 후반에 base64를 썻는지에 따라 처리!

            //****************************************************************
            //통 Block 방식
            byte[] decryptedBytes = decryptor.TransformFinalBlock(encryptedBytes, 0, encryptedBytes.Length);
            return Encoding.UTF8.GetString(decryptedBytes);
            //****************************************************************

            //Stream 방식 (1MB 이상이면 스트림 방식 권장)
            using (MemoryStream ms = new MemoryStream(encryptedBytes))
            {
                using (CryptoStream cs = new CryptoStream(ms, decryptor, CryptoStreamMode.Read))
                {
                    using (MemoryStream result = new MemoryStream())
                    {
                        cs.CopyTo(result);
                        return Encoding.UTF8.GetString(result.ToArray());
                    }
                }
            }
        }
    }
}







C#가 호환되는 자바쪽 소스 (GPT가 알려준 소스..!)

import javax.crypto.Cipher;
import javax.crypto.spec.IvParameterSpec;
import javax.crypto.spec.SecretKeySpec;
import java.util.Base64;

public class Test {
    // 주어진 AES 256-bit (32-byte) Key와 16-byte IV
    private static final String KEY = "0123456789abcdef0123456789abcdef"; // 32-byte
    private static final String IV = "abcdef9876543210"; // 16-byte

    public static String encrypt(String plainText) throws Exception {
        Cipher cipher = Cipher.getInstance("AES/CBC/PKCS5Padding");
        SecretKeySpec secretKey = new SecretKeySpec(KEY.getBytes(), "AES");
        IvParameterSpec ivParameterSpec = new IvParameterSpec(IV.getBytes());

        cipher.init(Cipher.ENCRYPT_MODE, secretKey, ivParameterSpec);
        byte[] encrypted = cipher.doFinal(plainText.getBytes("UTF-8"));

        return Base64.getEncoder().encodeToString(encrypted);
    }

    public static String decrypt(String encryptedText) throws Exception {
        Cipher cipher = Cipher.getInstance("AES/CBC/PKCS5Padding");
        SecretKeySpec secretKey = new SecretKeySpec(KEY.getBytes(), "AES");
        IvParameterSpec ivParameterSpec = new IvParameterSpec(IV.getBytes());

        cipher.init(Cipher.DECRYPT_MODE, secretKey, ivParameterSpec);
        byte[] decodedBytes = Base64.getDecoder().decode(encryptedText);
        byte[] decrypted = cipher.doFinal(decodedBytes);

        return new String(decrypted, "UTF-8");
    }

    public static void main(String[] args) {
        try {
            String originalText = "Hello, AES-256!";
            System.out.println("Original: " + originalText);

            String encryptedText = encrypt(originalText);
            System.out.println("Encrypted: " + encryptedText);

            String decryptedText = decrypt(encryptedText);
            System.out.println("Decrypted: " + decryptedText);
        } catch (Exception e) {
            e.printStackTrace();
        }
    }
}

IPC (Inter Process Communication) 방식 중 네임드파이프 통신이 있습니다.

서로 다른 프로그램에서 정의된 파이프 이름만 알면 통신이 가능한 방식입니다.

아래는 결과와 소스코드!



왼쪽은 A_Pipe, 오른쪽은 B_Pipe



using System;
using System.IO;
using System.IO.Pipes;
using System.Threading.Tasks;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class NamedPipe : Form
    {
        private const string myName = "A_Pipe"; //이름만 바꿔서 사용 가능
        private const string targetName = "B_Pipe"; //이름만 바꿔서 사용 가능

        private bool isOpen = true;

        public NamedPipe()
        {
            InitializeComponent();

            this.FormClosing += Form1_FormClosing;
            button1.Click += button1_Click;

            Task.Run(() =>
            {
                Receive();
            });
        }

        private void Receive()
        {
            while (isOpen)
            {
                try
                {
                    NamedPipeServerStream namedPipeServerStream = new NamedPipeServerStream(myName, PipeDirection.InOut, 10);
                    namedPipeServerStream.WaitForConnection(); //데이터 받을때까지 기다립니다.

                    StreamReader streamReader = new StreamReader(namedPipeServerStream);
                    string line = streamReader.ReadLine();

                    AddListItem(line);

                    streamReader.Close();
                    namedPipeServerStream.Close();
                }
                catch (Exception ex)
                {
                    AddListItem("Receive Error : " + ex.Message);
                }
            }
        }

        private void AddListItem(string message)
        {
            Invoke((MethodInvoker)delegate
            {
                listBox1.Items.Add(message);
            });
        }

        private void button1_Click(object sender, EventArgs e)
        {
            try
            {
                NamedPipeClientStream namedPipeClientStream = new NamedPipeClientStream(".", targetName, PipeDirection.InOut);
                namedPipeClientStream.Connect(10000); //10초

                StreamWriter streamWriter = new StreamWriter(namedPipeClientStream);

                streamWriter.WriteLine(textBox1.Text);
                streamWriter.Flush();

                streamWriter.Close();
                namedPipeClientStream.Close();
            }
            catch (Exception ex)
            {
                AddListItem("Send Error : " + ex.Message);
            }
        }

        private void Form1_FormClosing(object sender, FormClosingEventArgs e)
        {
            isOpen = false;
        }
    }
}

현재 영역에 대해서만 그려주기! (4개만 보이는 상태)



using System;
using System.Collections.Generic;
using System.Drawing;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form1 : Form, IMessageFilter
    {
        private const int buttonOffset = 10;

        private List<Button> buttonList = new List<Button>();
        private List<Control> focusedList = new List<Control>();
        private int scrollPosition;

        public Form1()
        {
            InitializeComponent();

            panel1.AutoScroll = true; //스크롤 활성화

            //스크롤 이벤트 등록
            this.panel1.Resize += new System.EventHandler(this.panel1_Resize);
            this.panel1.Scroll += new System.Windows.Forms.ScrollEventHandler(this.panel1_Scroll);

            //버튼 이벤트 등록
            this.button_add.Click += new EventHandler(this.button_add_Click);

            Application.AddMessageFilter(this); //IMessageFilter 사용하기 위해 등록!
        }

        public bool PreFilterMessage(ref Message m) //IMessageFilter 콜백
        {
            if (m.Msg == 0x20a) // WM_MOUSEWHEEL (마우스 휠)
            {
                if (panel1.Bounds.Contains(PointToClient(Cursor.Position)))
                {
                    short x = (short)(((int)m.WParam >> 16) & 0xffff);

                    if (x < 0)
                    {
                        ScrollMove(20);
                    }
                    else
                    {
                        ScrollMove(-20);
                    }

                    return true;
                }
            }

            return false;
        }

        private void ScrollMove(int move)
        {
            int preValue = scrollPosition;

            scrollPosition += move;
            scrollPosition = Math.Max(scrollPosition, 0);
            scrollPosition = Math.Min(panel1.DisplayRectangle.Width - panel1.Width, scrollPosition);

            panel1.HorizontalScroll.Value = scrollPosition;

            //기존 값과 같다면 동작하지 않게 합니다.
            if (preValue == scrollPosition)
            {
                return;
            }

            UpdateThumbnail(scrollPosition);
        }

        private void button_add_Click(object sender, EventArgs e)
        {
            Button button = new Button();

            button.Text = buttonList.Count.ToString("D4");
            button.Hide();

            panel1.Controls.Add(button);
            panel1.AutoScrollMinSize = new Size(panel1.AutoScrollMinSize.Width + button.Width + buttonOffset, 0);

            buttonList.Add(button);
            UpdateThumbnail(scrollPosition);
        }

        private void UpdateThumbnail(int startPosition)
        {
            int totalWidth = 0;

            //돌면서 그려줘야 할 영역에 대해서만 그려주기!
            for (int i = 0; i < buttonList.Count; ++i)
            {
                totalWidth += buttonList[i].Width + buttonOffset;

                //처음으로 커지는 구간을 찾기! 시작 지점!
                if (totalWidth >= startPosition)
                {
                    int showPositionX = totalWidth - startPosition - buttonList[i].Width - buttonOffset;

                    List<Control> newFocusList = new List<Control>();

                    for (int j = i; j < buttonList.Count; ++j)
                    {
                        Point position = new Point(showPositionX, 0);
                        showPositionX += buttonList[j].Width + buttonOffset;

                        buttonList[j].Location = position;
                        buttonList[j].Show();

                        newFocusList.Add(buttonList[j]);

                        if (this.Width <= showPositionX)
                        {
                            break;
                        }
                    }

                    //현재 영역에 들어있지 않은 기존 항목은 제거해줍니다.
                    foreach (Control item in focusedList)
                    {
                        if (newFocusList.Contains(item) == false)
                        {
                            item.Hide();
                        }
                    }

                    //현재 항목을 갱신합니다.
                    focusedList = newFocusList;

                    break;
                }
            }
        }

        private void panel1_Scroll(object sender, ScrollEventArgs e)
        {
            scrollPosition = e.NewValue;
            Console.WriteLine("scrollPosition : " + scrollPosition);
            UpdateThumbnail(scrollPosition);
        }

        private void panel1_Resize(object sender, EventArgs e)
        {
            if (panel1.AutoScrollMinSize.Width - panel1.Width <= scrollPosition)
            {
                Console.WriteLine("*************************** 크기 변경!!!");

                scrollPosition = Math.Max(0, panel1.AutoScrollMinSize.Width - panel1.Width);
                panel1.HorizontalScroll.Value = scrollPosition;
            }

            UpdateThumbnail(scrollPosition);
        }
    }
}



이미지 회전에 따른 여백 생성!



우선은 코드만 올립니다..

using System;
using System.Diagnostics;
using System.Drawing;
using System.IO;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form1 : Form
    {
        private string workFolder = Path.Combine(Application.StartupPath, "workFolder");
        private int sequence = 0;

        public Form1()
        {
            InitializeComponent();

            //이미지 확인을 위해 오토사이즈로 해줍니다.
            pictureBox1.SizeMode = PictureBoxSizeMode.AutoSize;
            pictureBox2.SizeMode = PictureBoxSizeMode.AutoSize;
        }

        private void button1_Click(object sender, EventArgs e)
        {
            OpenFileDialog ofd = new OpenFileDialog();

            //파일을 불러옵니다.
            if (ofd.ShowDialog() == DialogResult.OK)
            {
                pictureBox1.Image = Image.FromFile(ofd.FileName);
            }
        }

        private void button2_Click(object sender, EventArgs e)
        {
            if (Directory.Exists(workFolder) == false)
            {
                Directory.CreateDirectory(workFolder);
            }

            sequence++; //돌린 횟수! (파일명 겹치지 않도록 해줍니다.)
            Image originImage = pictureBox1.Image; //사용될 원본 이미지!

            for (int rotation = 1; rotation <= 360; ++rotation) //360도 회전시켜줍니다.
            {
                int maxAngle = 91;

                int width = originImage.Width;
                int height = originImage.Height;

                int rot; //항상 0 ~ 90도로 만들어줍니다.

                if (90 < rotation && rotation <= 181) //해당 구간에서는 반전이 필요합니다.
                {
                    rot = 180 - rotation;
                }
                else if (270 < rotation && rotation <= 360) //해당 구간에서는 반전이 필요합니다.
                {
                    rot = 360 - rotation;
                }
                else
                {
                    rot = rotation % maxAngle;
                }

                double widthRadian = rot * Math.PI / 180;
                double heightRadian = (90 - rot) * Math.PI / 180; //90도 기준으로 반전 시켜줍니다.

                double w = Math.Cos(widthRadian) * width + Math.Sin(widthRadian) * height;
                double h = Math.Cos(heightRadian) * width + Math.Sin(heightRadian) * height;

                //기존 이미지 기준으로 돌려줍니다.
                DrawImage(originImage,
                          pictureBox1,
                          rotation,
                          width,
                          height,
                          width,
                          height,
                          "origin_");

                //크기가 확장 된 이미지 기준으로 돌려줍니다.
                DrawImage(originImage,
                          pictureBox2,
                          rotation,
                          (int)w,
                          (int)h,
                          width,
                          height,
                          "extend_");
            }

            originImage.Dispose();

            Process.Start(workFolder);
        }

        private void DrawImage(Image originImage,
                                PictureBox pictureBox,
                                int rotation,
                                int width,
                                int height,
                                int centerX,
                                int centerY,
                                string imageType)
        {
            Color backgroundColor = Color.FromArgb(255, 255, 0, 0);      //빨강 배경 (알파값을 통해 투명하게 가능!)

            Bitmap bitmap = new Bitmap(width, height);
            Graphics graphics = Graphics.FromImage(bitmap);

            graphics.Clear(backgroundColor);                             //배경 칠해주기
            graphics.TranslateTransform(width / 2, height / 2);          //이미지 가운데로 이동
            graphics.RotateTransform(rotation);                          //가운데에서 회전
            graphics.DrawImage(originImage, centerX / -2, centerY / -2); //이미지를 가운데 그려줍니다.

            string fileName = string.Format("{0}_{1}{2}.png", sequence.ToString("D4"), imageType, rotation.ToString("D4"));
            string savePath = Path.Combine(workFolder, fileName);

            bitmap.Save(savePath);

            graphics.Dispose();
            bitmap.Dispose();

            pictureBox.Image = Image.FromFile(savePath);
            pictureBox.Update();
        }
    }
}





간단한 용어 정리

Invoke : 메인 쓰레드에서 동작하도록 해주는 기능 (다른 스레드 => 메인UI 스레드 동작 시켜줌)

InvokeRequired : Invoke가 필요한 상황인지 체크. (메인UI 스레드 != 현재 실행중인 스레드 체크)



Windows Form에서 UI는 메인 스레드에서만 변경이 가능하며 그 외의 접근에 대해서는 예외가 발생됩니다.



우선 사용 방법은 다음과 같습니다. 방법1 혹은 방법2를 참고하여 사용하면 됩니다.

(예외와 주의 사항은 더 아래쪽에 적어두겠습니다.)

using System;
using System.Threading;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form3 : Form
    {
        //방법2를 위한 delegate ******************
        private delegate void SetLabelDelegate();
        private SetLabelDelegate setLabelDelegate;
        //****************************************

        private string message1 = "";
        private string message2 = "";
        private string message3 = "";

        public Form3()
        {
            InitializeComponent();

            //방법2를 위한 delegate 등록 *************
            setLabelDelegate += SetLabel;
            //****************************************
        }

        private void button1_Click(object sender, EventArgs e)
        {
            Thread thread = new Thread(ChangeUI);

            message1 = "mainThread " + AppDomain.GetCurrentThreadId().ToString();
            thread.Start();
        }

        private void ChangeUI ()
        {
            message2 += "subThread " + AppDomain.GetCurrentThreadId().ToString();

            if (InvokeRequired)
            {
                //방법1. MethodInvoker, delegate 조합
                Invoke((MethodInvoker)delegate
                {
                    message3 = "InvokeThread " + AppDomain.GetCurrentThreadId().ToString();
                    SetLabel();
                });

                //방법2. delegate 호출
                //Invoke(setLabelDelegate);
            }
            else
            {
                SetLabel();
            }
        }

        private void SetLabel ()
        {
            label1.Text = message1;
            label2.Text = message2;
            label3.Text = message3;
        }
    }
}



결과 (SetLabel은 메인쓰레드 7724로 실행)





오류 예시.

[System.InvalidOperationException - Cross Thread]

: 메인 스레드가 아닌 다른 스레드에서 UI 변경을 한 경우 발생

using System;
using System.Threading;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form3 : Form
    {
        public Form3()
        {
            InitializeComponent();
        }

        private void button1_Click(object sender, EventArgs e)
        {
            Thread thread = new Thread(ChangeUI);

            MessageBox.Show(AppDomain.GetCurrentThreadId().ToString()); //main thread number
            thread.Start();
        }

        private void ChangeUI ()
        {
            MessageBox.Show(AppDomain.GetCurrentThreadId().ToString()); //other thread number
            label1.Text = "1";
        }
    }
}



결과 : 당연하게 오류 발생





주의 사항)

 쓰레드 번호를 확인할 수 있도록 코드를 작성해놨습니다.

이것으로 현재 함수가 어떤 쓰레드에서 실행 중인지 볼 수 있는데,

Invoke를 통해 MainThread -> SubThread -> MainThread 방식의 흐름이 가능합니다.

반드시 필요한 곳에서만 Invoke를 사용해야 올바른 비동기 코드가 진행이 될 수 있습니다.

잘 못된 코드와 올바른 코드 예시를 남깁니다.



using System;
using System.Threading;
using System.Windows.Forms;

namespace WindowsFormsApp1
{
    public partial class Form3 : Form
    {
        public Form3()
        {
            InitializeComponent();
        }

        private void button1_Click(object sender, EventArgs e)
        {
            Thread validInvokeThread = new Thread(ChangeUI);
            validInvokeThread.Start();

            //이렇게 호출되면 안됨.
            //Thread invalidInvokeThread = new Thread(ChangeUI2);
            //invalidInvokeThread.Start();
        }

        private void ChangeUI()
        {
            //스레드 동작과 메인UI 스레드가 원하는대로 잘 동작하게 됩니다.
            SetLabel(label1, AppDomain.GetCurrentThreadId().ToString());
            Thread.Sleep(1000);
            SetLabel(label2, AppDomain.GetCurrentThreadId().ToString());
            Thread.Sleep(1000);
            SetLabel(label3, AppDomain.GetCurrentThreadId().ToString());
        }

        private void ChangeUI2()
        {
            //이렇게 사용하면 MainThread에서 모든 것을 처리해주게 됩니다.
            //즉 "스레드의 사용 의미가 없다" 입니다.
            if (InvokeRequired)
            {
                Invoke((MethodInvoker)delegate
                {
                    ChangeUI2();
                });
            }
            else
            {
                SetLabel(label1, AppDomain.GetCurrentThreadId().ToString());
                Thread.Sleep(1000);
                SetLabel(label2, AppDomain.GetCurrentThreadId().ToString());
                Thread.Sleep(1000);
                SetLabel(label3, AppDomain.GetCurrentThreadId().ToString());
            }
        }

        private void SetLabel(Label label, string text) //delegate로 함수를 만들어서 처리도 가능
        {
            if (InvokeRequired)
            {
                Invoke((MethodInvoker)delegate
                {
                    label4.Text = "메인스레드 : " + AppDomain.GetCurrentThreadId().ToString();
                    label.Text = text;
                });
            }
            else
            {
                label4.Text = "메인스레드 : " + AppDomain.GetCurrentThreadId().ToString();
                label.Text = text;
            }
        }
    }
}



ChangeUI (UI는 메인에서, Sleep은 다른 스레드에서 처리)

ChangeUI2 (메인 스레드에서 처리. Sleep에 의해 멈추기도함)



[디렉토리 이동]

cd

예시) cd C:\       (띄어쓰기 등이 있는 경우는 "  " 로 감싸주기)



[파일 확인]

dir

예시) dir



(공통 옵션)

/s - 하위목록도 삭제

/q - 삭제여부 확인 x



[파일 삭제]

del

예시) del /s /q *.txt



[폴더 삭제]

rmdir

예시) rmdir /s /q C:\temp\....

MSBuild.exe 파일의 경로를 찾아줍니다.



 ex) 전 2019 Community 버전을 사용하고 있습니다.

    C:\Program Files (x86)\Microsoft Visual Studio\2019\Community\MSBuild\Current\Bin



text 파일로 아래와 같이 작성을 해준 후 .bat 파일로 저장하면 완성입니다!



:msbuild 파일이 있는 곳으로 이동 (참고로 배치에서 : 은 주석!)
cd C:\Program Files (x86)\Microsoft Visual Studio\2019\Community\MSBuild\Current\Bin

:빌드할 솔루션 지정
msbuild C:\Users\dlaeh\source\repos\WindowsFormsApp1\WindowsFormsApp1.sln

: 결과를 보고 싶으면 pause 명령을 통해 멈춰줍니다.
pause



해당 배치파일 실행한 결과!!



좀 더 옵션을 줄 수도 있습니다.



:msbuild 파일이 있는 곳으로 이동
cd C:\Program Files (x86)\Microsoft Visual Studio\2019\Community\MSBuild\Current\Bin

:빌드할 솔루션 지정
msbuild C:\Users\dlaeh\source\repos\WindowsFormsApp1\WindowsFormsApp1.sln /t:Rebuild /p:Configuration="Release" /p:Platform="Any CPU"

:/t:Rebuild 		재빌드
:/p:Configuration="Release"   	디버그 혹은 릴리즈 혹은 사용자 지정 세팅
:/p:Platform="Any CPU"  	타겟 플랫폼 지정
:/v:quiet 			조용히 빌드하기

: 결과를 보고 싶으면 pause 명령을 통해 멈춰줍니다.
pause



Configuration과 Platform 은 구성 관리자에서 추가도 가능합니다.





'기타 > 유용한 것' 카테고리의 다른 글

[cmd] 명령어 정리하기  (0) 2024.04.20
SFTP 구축 및 연결 (freeFTPd, WinSCP/FileZilla)  (0) 2023.04.09
NSIS 설치 파일 만들기  (0) 2022.08.18

+ Recent posts
